Ya-maha Motorcycle Immo Emulator 2006-2009 Scooter Bike

Ya-maha Immo Emulator

• Emulate an immobilizer for motorcycles and scooters Ya-maha
• Works with all motorcycles and scooters Ya-maha from 2006 to 2009.
• Not demand programming. only need is connect wires.
• Completely emulates work of a regular immobilizer, including light-emitting diode work on the instrument panel.
• Large quantity in stock

For emulator installation in the case of a regular immobilizer:

1. Remove glue hermetic from the immobilizer case.

2. Take out a PCB from immobilizer and desolder from it wires.

3. Connect the emulator according to drawing more low.

4. Insert the emulator into immobilizer case.

Colouring of wires and their appointment:

Black (2 pcs.)  GND

Red  BATT (+12v)

Yellow IGN (+12v)

Gray  LED (+5v)

Blue K-line Immo-ECU
