TMS374 ECU Decoder
Top 4 Reasons To Get TMS374 ECU Decoder
1. Power the sweeper and ECU
2. Connect the GND line to any suitable GND on the ECU
3. Connect the Data line to the Reset pin on the 27C512 or 28F512
4. Without the need of a laptop
TMS-374 Decoder ECU info
A small tiny2313 MCU is used to generate the pulses instead of the PC RS232 Tx line. The TMS 374 software is in fact a simple frequency sweeper with an effective range from about 2000Hz to about 100Hz. The Tiny sweeper does exactly the same but much more better (bigger range).
After powering the device on - the LED should blink twice. Pressing the button will start the sweep procedure. LED ON - means there are pulses on the output. After reaching the lowest frequency the LED goes off and the mcu stops the generation.
The sweeper should work with the following ECUs:
Renaul*t SIEMENS Fenix 3 and 5
Renaul*t Megane 1400cc 8v
Renaul*t Megane 1600cc 8v
Renaul*t Megane 2000cc 8v
Renaul*t Megane 2000cc 16V
Renaul*t Megane Scenic 1400cc 8v
Renaul*t Megane Scenic 1600cc 8v
Renaul*t Megane Scenic 2000cc 8v
Renaul*t Sefrane 2000cc 16V
Renaul*t Laguna 2000cc 8v
Renaul*t Laguna 2000cc 16v
Renaul*t Espace 2000cc 8v
Renaul*t SAGEM SAFIR 1 and 2
------------------------------
Renault Clio 1200cc 8V
Renault Clio 1400cc 8V
Renaul*t Clio 1600cc 8V
Renaul*t Clio 2000cc 16V Williams
Renaul*t Laguna 1800cc 8V
Renaul*t Laguna 2000cc 8V
Renaul*t Laguna 1800cc 16V
Renaul*t Laguna 2000cc 16V
Renaul*t Twingo 1200cc 8V
Sagem SL96 Psa
--------------------
Peugeo*t 306 1400cc 8V
Peugeo*t 306 1600cc 16V
Peugeo*t 306 1800 16V
Peugeo*t Ranch 1400 8V
Citroe*n Berlingo 1400cc 8V
Citroe*n Xrara 1400cc 8V
Citroe*n Xrara 1800cc 16V
DAEWOO SIEMENS
-------------------
Daewoo Matiz 800cc
HYUNDA*I SIEMENS
-------------------
Hyunda*i Coupe 1600cc 16V
Hyunda*i Coupe 2000cc 16V
KIA SIEMENS
--------------
Kia Rio 1300 16V
Kia Rio 1500 16V
MAGNETI MARELLI
------------------
1AP20, 1AP40, 1AP41, 1AP43
1AP80, 1AP81, 1AP83 1AP90
Citroe*n Berlingo 1800cc 8V
Citroe*n Saxo 1400cc 8V
Citroe*n Saxo 1600cc 16V
Citroe*n Xara 1400cc 8V
Citroe*n Xara 1800cc 8V
Citroe*n Xara 2000cc 16V
Citroe*n ZX 1400cc 8V
Peugeo*t 106 1400cc 8V
Peugeo*t 106 1600cc 8V
Peugeo*t 106 1600cc 16V
Peugeo*t 206 1100cc 8V
Peugeo*t 206 1400cc 8V
Peugeo*t 306 1400cc 8V
Peugeo*t 306 1600cc 8V
Peugeo*t 306 1800cc 8V
Peugeo*t 405 1800cc 8V
Peugeo*t 406 1800cc 8V
Peugeo*t Partner 1800 8V
A handy tool to have that will decode an all the above ecu's to a new state without the need of a laptop
Package including:
1pc x TMS374 ECU Decoder
